At a glance

Built properly.
Chosen confidently.

Everything important is visible before you order. We’ll then check your access, base and preferred positioning with you personally.

Footprint: 6 × 10 ft
Cladding: 33mm interlocking logs
Roof style: Pent
Doors: Glazed double
Windows: Large-pane glazing
Range: Modern Style
Overall height: 225 cm
Overall width: 300 cm
Overall depth: 180 cm
Nominal size: 6ft x 10ft
Cladding thickness: 33mm
Internal Height: 2.14 x 1.93m
Door width: 1200mm
Door height: 1800mm
Door security: Mortice Lock
Expected lead time: 10 - 12 weeks

Complete product information

Everything that comes
with this building.

The construction, included features and available choices for this exact design are set out below. We’ll confirm the final combination with you before manufacture.

01

Specification

Pent roof log cabin
33mm interlocking tongue & groove logs
Floor and roof made from 15mm tongue & groove shiplap
Joinery quality hardwood double door with mortice lock
Joinery quality hardwood opening window
Toughened glass as standard
Supplied untreated in kit form, doors and window are pre-hung in a frame
Reversible door & window positions

02

Available options

Side window position: Central
Side window position: Towards front
Choose your basework: I already have a suitable level base — No basework added — no extra charge
Choose your basework: 2 × 2-inch timber bearers — Treated timber bearers for a suitable prepared surface — +£162.31 including VAT
Choose your basework: 3 × 3-inch timber bearers — Deeper treated timber bearers for a suitable prepared surface — +£250.46 including VAT
Choose your basework: Brick-and-bearer base — Brick supports with timber bearers — +£388.98 including VAT
Choose your basework: Floating base — A level floating base prepared for the building — +£520.50 including VAT
Choose your basework: Concrete base — A solid concrete base prepared for the building — +£1,069.20 including VAT
Factory treatment for the floor and roof — price confirmed by Elford
Small-pane Georgian-design doors and window — price confirmed by Elford
Green felt roof shingles — price confirmed by Elford
Rubber sheet roof covering instead of felt — +£233.55

Before you order

Delivery, base
& care.

01Measurements+

Building dimensions are approximate external measurements. Allow for roof overhangs, installation access and ongoing maintenance space; confirm any critical internal or external dimension before ordering.

02Delivery and access+

Lead times vary through the year. Before manufacture, access should be checked for height restrictions, narrow gates and sharp turns because larger wall and roof panels need a clear route into the garden.

03Base requirements+

Install the building on a solid, flat and level base. A correctly prepared base helps the panels align, keeps the doors operating properly and supports the building throughout its life.

04Timber treatment+

Natural timber must be treated promptly and then maintained regularly with a suitable exterior wood preservative. Give particular attention to joints, end grain and areas exposed to persistent moisture.

05Guarantee and natural timber+

The standard guarantee covers faulty parts and workmanship for 12 months. Timber naturally expands, contracts and may show knots, splits or resin pockets; regular treatment and ventilation remain essential.

✦
